Airbus A340-500 NEUFLUGZEUG 237 PAX, 2 AC available |
[VERKAUFT] US$ 150.000.000 |
Übersicht
Übersicht | Typ: | Jet | Hersteller: | Airbus | Modell: | A340-500 NEUFLUGZEUG 237 PAX, 2 AC available | Baujahr: | 2012 | RegistrierungsNr.: | TBA | Eigenschaften: | IFR zugelassen IFR ausgerüstet Gewerblich zugelassen EU-OPS 1 zugelassen | Standort: | Deutschland | Gesamtzeit (TTAF): | 10 h | Preis: | US$ 150.000.000 (~ € 142.761.968)[VERKAUFT] | Netto-Preis: | € 142.761.968 US$ 150.000.000 | EU-versteuert: | nein | MwSt. ausweisbar: | nein | Alle Details |
Anbieter |
Carlos de Pilar Flugzeughandel www.carlos-de-pilar.de Postfach 1529 D-82157 Gräfelfing Deutschland
Tel.: [+49] - (0)89 - 8542303 Fax: [+49] - (0)89 - 853176 |
Kontakt zum Anbieter |
|
|
|
Details
Übersicht | Typ: | Jet | Hersteller: | Airbus | Modell: | A340-500 NEUFLUGZEUG 237 PAX, 2 AC available | Baujahr: | 2012 | RegistrierungsNr.: | TBA | Eigenschaften: | IFR zugelassen IFR ausgerüstet Gewerblich zugelassen EU-OPS 1 zugelassen | Standort: | Deutschland | Gesamtzeit (TTAF): | 10 h | Preis: | US$ 150.000.000 (~ € 142.761.968)[VERKAUFT] | Netto-Preis: | € 142.761.968 US$ 150.000.000 | EU-versteuert: | nein | MwSt. ausweisbar: | nein |
Motor(en) | Anzahl Motoren: | 2 | Hersteller/Modell: | RR TRENT 556A2-61 | RR TRENT 556A2-61 |
Beschreibung/Details Motoren | RR TRENT 556A2-61 |
Avionik | ATA 22 Auto flight
FMS (Genepi/P3HJ0) alternate equipment - HONEYWELL (A340 with RR engines)
ATA 23 Communications
System provision for Tailwind 560 system interfaced with Thales i-5000 system
Installation of Tailwind 560 system interfaced with Thales i-5000 system
Selection of Thales i-5000 IFE system
Entertainment system
CIDS changes
IFE media content loading at final assembly line
Installation of PC-Board for cabin FAPs
Installation of high speed SATCOM - four channels (4 x 64kb/s) -
HONEYWELL (MCS-7200)
Provision of high speed data SATCOM - HONEYWELL HS720 with AINS/CINS
capabilities
Additional i-5000 data wiring - cabin redundancy at FDB-FDB level
Access to ONAIR services installed on ALNAv1 CNSU via RJ45 in-seat plugs of
THALES i5000 IFE
Seat to seat wiring Thales i-5000
FAP pages definition
Cabin lighting scenario definition
AAP definition
Lighting control definition
PRAM functions from IFE and controlled via IFE control panel - Thales i-5000
Social area - video monitor installation in bar backdrop monument
Advanced CIDS functions for lighting scenario control
Cabin lighting preset selection
Relocation of AIP and CIDS handset in door 2 area
Adaptation of the IFE Data/Power distribution
Relocation of AIP and CIDS handset in door 3 area
TW560 system Configuration
Kingfisher Class Social area - Video monitor installation
CIDS Global RFC update - 4 Zone cabin illumination
CVR bulk erase facility deactivation
Installation of TWLU (WLU2100) and antenna - ROCKWELL COLLINS (SFE)
BC seat audio jack type change
Installation of self-programmable ELT through a programming dongle - THALES
AVIONICS
Dual HFDR system - HONEYWELL
VDR transceivers capable mode 2 - HONEYWELL
Boomsets alternate equipment - SENNHEISER - HME045-250-025
Installation of headset - SENNHEISER type HD45-K - PN 045-260-011
Installation of an Audio Control Panel (ACP) and jack panel in avionics
compartment
Installation of Cockpit Door Surveillance System (CDSS) connected to the
ECAM SD
CVR HONEYWELL |
Ausstattung | Rudder leading edge painting according to vertical stabilizer dominant colour
External livery
Painting of the visible THS travel area in the customer's livery
Cabin and cabin systems equipment turned from BFE into SSBFE
All avionics turned from BFE into SSBFE
Decals turned from BFE into SSBFE
Gold Pantone 871C paint supplier change
15 knots tailwind operations at take-off (RR engines)
Compliance status report with FAR 121-subparts J and K requirements
ATA 03 Design weights
MTOW: 380T, MLW: 246T, MZFW: 232T
ATA 11 Placards and markings
Deletion of the standard seat row numbering in B/C area
Installation of specific placards
MSN number and design weights placard in the cockpit
Emergency cut-out markings
Installation of Non Smoking placards in the two social areas
Installation of leasing plate on engines
Installation of leasing plate on forward LH passenger door
Installation of leasing plate on cockpit rear partition
Weight indication in kg and lb for cargo compartments
ATA 21 Air conditioning
Installation of air outlets in the B/C social area
Particle and odors filter element PALL-GMBH
System provisions for individual air outlets in all lavatories
Installation of forward cargo compartment ventilation system and temperature
control
Combined VOC/ozone catalytic converters alternate equipment - ENGELHARDT
ATA 24 Electrical power
Battery discharge warning system
ATA 25 Equipment / Furnishing
Bulk Crew Rest Compartment definition
Installation of electrical galley catering equipment (BFE)
Cabin layout definition
Installation of non-electrical galley catering/loose equipment (BFE)
Lavatory equipment selection
Cabin emergency equipment
Galley cooling
In-Seat Power Supply System Changes
Application of additional anti-skid paint on floor panels
Installation of emergency medical kit in cabin (BFE) --- AEROMEDIC
INNOVATIONS, PN 520001---37
Installation of first aid kits in cabin (SFE)-AEROMEDIC INNOVATIONS, PN 52001-25
Installation of 2 additional flashlights in cockpit
Installation of spare safety belts (BFE) - AMSAFE, PN 2090-1-022-0585
Installation of carry off bags for ELT - Thales Avionics S.A., PN S1820511-03(BFE)
Installation of safety belt extensions (BFE) - AMSAFE, PN 2090-2-012-0585
Installation of infant safety belts (BFE) - AMSAFE, PN 2090-5-012-0585
Installation of demo safety belts (BFE) - AMSAFE, PN 2090-6-012-0585
PSU adaptation for reading light configuration
Installation of customized endcaps in BC high ceiling
Installation of F/C standard high ceiling in B/C area
Door 2 social area ceiling and lining customization
Installation of large lateral raceways under carpet for BC area
Installation of folding trolleys for B/C (BFE)
Installation of folding trolleys for Y/C (BFE)
Galleys floor thermal insulation
Installation of a window in lavatories L35 and L36
System connection for bar at door 2 center
Installation of lockable compartment in OHSC
Installation of a GWDU in galley G6 - LGG
Installation of flower holder (BFE) in the B/C lavatories
Installation of a window in lavatory L38
Installation of specific key latch in the BFE stair house of the BCRC
Installation of lockable stowage compartments in BCRC
Installation of door 2 social area bar and stools (BFE)
Installation of C2C back drop bar in door 2 social area (BFE)
Installation of baby bassinets (BFE)
System connections for chilled galley G3L
Installation of door 2 social area closets, sofas and partitions (BFE)
Nursing table installation in lavatory A
Installation of galley G4 (BFE)
Installation of half size galley G5 (BFE) at door 4 in combination with BCRC
staircase
Installation of a cosmetic shelf in lavatory L11
Lavatory wash basin accessibility and use improvement
Deletion of lateral OHSC at door 3
Specific curtain installation and installation of header panels
Installation of OHSC door spacer for light tight separation between B/C and Y/C
Installation of a customized pelmet and partition for EC social area at Door 3 (BFE)
Stretcher loading capability for lavatory module Y
Interior color scheme definition
Installation of specific OHSC arrangement
Change of decor laminate on monuments
Installation of a water switch sensor - Thales Avionics (SFE)
NTF installation for lavatories - BFE - Schneller - S009976
Provision for an Air Cooling Unit for central galley G4 in door 3 ceiling area
NTF installation for exit and galley areas with Wulfmeyer backing - SFE -Top layer
Schneller/Panflor
Installation of door 3 screen off solution
Cabin emergency equipment PN change
Installation of wall mounted CAS fwd of lavatory L36
Installation of a window in lavatories L53 and L54
Installation of padded seat support in lavatories L35, L36, L38 and L54
Installation of a double pilot compartment and a seat in BCRC pilot area
Installation of floor-mounted cabin attendant seat aft of door 3, LH
Installation of medical outlets panel (230 VAC/50 hHz and 115 VAC/60 Hz)
aft of the cabin LH
Installation of Galley/Bar unit fwd of door 3 (BFE)
Installation of A380 bumpers
Installation of non-electrical galley catering/loose equipment (BFE) (Change 1)
Installation of electrical galley catering equipment (BFE) (Change 1)
Baby nursing table in lavatory L73
Baby nursing table in lavatory L74
Installation of baby bassinets - quantity change
Installation of one pair of fireproof gloves BENNETT PN FKK8-35KL (SFE)
Deletion of standard magazine racks fwd of door 3
Installation of door 2 screen off solution (BFE) - revised definition
Installation of electrical galley catering equipment (BFE) (Change 2)
Modification of captain and first officer document stowages
Installation of sidewall lining protections in cargo compartment
Application of Second level of enhanced cargo loading system
Flashlight DME, PN P2-07-0001-214 (SFE)
ATA 26 Fire protection
Portable fire extinguisher TOTAL, PN 74-20 (SFE)
APU fire extinguisher WALTER KIDDE
Engine fire extinguishers WALTER KIDDE
ATA 27 Flight controls
Flap track 'sealed for life' roller bearings - KAMATICS
ATA 29 Hydraulic power
Electro pumps (EMP) EATON AEROSPACE
ATA 31 Indicating/Recording
FDR (256 w/s) - HONEYWELL
Installation of cockpit display units with video capability
Rising runway on PFD
ATA 32 Landing Gear
A340-500 - Wheels and brakes GOODRICH MESSIER
A340-500 - Radial light weight tires (NZG) (MLG, CLG) - MICHELIN
A340-500 - Radial tires (NLG) - MICHELIN
ATA 33 Lights
Cabin lighting changes
Installation of star effect lighting in B/C - fiber optic
Special installation of floor-mounted EEPMS LUFTHANSA TECHNIK in NTF covered
area
Lavatory occupied sign on BCRC information column
Lavatory occupied signs requirements
Door 1 area lighting
Social area lighting
Galley G1C lighting
Kingfisher Class Social area lighting
Provision for light power supply in Stowages and Galleys
Installation of illuminated Return To Seat signs
Installation of spotlights with warm lighting
Illumination of the mirror in the BCRC changing area
Installation of additional emergency light in BCRC flight crew are
ATA 34 Navigation
Pitot probes THALES AVIONICS - PN C16195BA
Compliance with European enHanced Surveillance (EHS) regulation
Improved radio altimeter HONEYWELL Quantum line
ISIS - display of metric altitude
Dual weather radar (ARINC 708A) HONEYWELL with PWS, autotilt activation and
new dual antenna mount
TCAS (Ch7) - Honeywell (TPA 100) / ATC EHS - Honeywell (-1402)
DME HONEYWELL quantum line
Wiring provisions for the European enhanced surveillance
Installation of a single ADF - HONEYWELL (Quantum line)
MMR HONEYWELL
ATA 35 Oxygen
Portable oxygen cylinder/mask assembly in cabin - AVOX SYSTEMS (11.0 cuft)
(SFE) - PN 3552AAADAACXCD
Extended duration gaseous passenger oxygen system with Advanced
Oxygen Regulator (AROX)
Installation of one additional mask in each oxygen box (gaseous system)
One PBE with white box in cockpit - B/E Aerospace, PN 119003-11 (SFE)
ATA 38 Water / Waste
Installation of one water conditioner in potable water system
Installation of a filter in potable water supply
ATA 46 Information systems
Installation of Server Interface Unit (SIU) - ROCKWELL COLLINS (SFE),
PN 822-1637-101
Installation of Aircraft Network Server Unit (ANSU) - ROCKWELL COLLINS (SFE),
PN 822-2169-101
Installation of Ethernet Switch Unit (ESU) - ROCKWELL COLLINS (SFE),
PN 822-1771-001
System provisions for ALNA V1 MILTOPE CNSU
System provisions for ALNA V2 with ONAIR
Installation of ALNA V1 Cabin Network Server Unit (CNSU) - SFE
Installation of ONAIR application software (SFE)
Installation of three CWLUs (WLU2100) and six antennas - ROCKWELL COLLINS
(SFE)
Activation of ARINC 623 in the ATSU
Activation of VDL mode 2 function in the ATSU
ATA 51 Structure - general
Alternate paint systems (LOW VOC / CF primer) on nacelles --- PPG AEROSPACE
Application of adhesive decorative films (decal) on vertical stabilizer and
nacelles (BFE)
Application of adhesive decorative films (decal) on fuselage "first" logo (BFE)
Intermediate coat paint system (LOW VOC/CF primer) on fuselage and
vertical stabilizer - PPG AEROSPACE
Intermediate coat paint system (LOW VOC/CF primer) fuselage and vertical
stabilizer - ANAC
Alternate paint systems (LOW VOC / CF primer) on nacelle - ANAC
ATA 52 Doors
Installation of deadbolt for manual locking of reinforced cockpit door
Installation of a retractable ladder on avionics compartment access door
ATA 55 Stabilizers
Metal sheet cover on vertical stabilizer
ATA 56 Windows
PPG front and side windows (Chemically tempered) |
Bemerkungen/Sonstiges | 2 Sister Aicraft available priced 150.mio each |
Fotos
Kontakt zum Anbieter
|
